UL ultimate vault doors we are launching, just as the name suggests, feature rigid structures and aesthetic outlooks. The state-of-the-art craftsmanship includes the interior and the outside grid are quality components of top quality.


STB timer
Swiss-made STB LCD timer with tolerance of less than 1 minute and free adjustment of time. In case of emergency, the setting is canceled. Maximum setting time of 299 hours. UL BP8782.		 Combination lock
To unlock the safe deposit, it is enough to unlock any 2 of the 3 sets of mechanical combinations. In case of trouble, a third set would become available for unlocking. 		Emergency ventilation system
In case of people locked in the safe deposit, by pushing the handle to a specific point from the inside, the system would proceed with the following:

1.

Electric fan would go on for fresh air.
2.  Open the alarm system.
3.  Communication with the outside for rescue.

Specifications

Model

Class

Vault Door

Dimension

Wall Thickness

STB
timer

Combination
Lock

Ventilation

Grid

Re-locking

Security

9000M

M

60 mm

836 x 1977mm

270 mm

1 set

3 sets

option

●

●

●

99901

Ⅰ

90 mm

936 x 1977mm

340 mm

1 set

3 sets

●

●

●

●

99902

Ⅱ

130 mm

936 x 1977mm

340 mm

1 set

3 sets

●

●

●

●

99903

Ⅲ

210 mm

936 x 1977mm

500 mm

1 set

3 sets

●

●

●

●

Remarks :

1. " ●  " Mark for standard device
2. Specifications change without notice
